The ATSAMD10-XMINI is an Atmel ATSAMD10 Xplained mini board, a hardware platform to evaluate the ATSAMD10 microcontroller. The ATSAMD10 32bit, ARM Cortex-M0+, low power microcontroller operating at a maximum frequency of 48MHz. The evaluation kit comes with a fully integrated debugger that provides seamless integration with Atmel Studio 6.2 and later version. The kit provides access to the features of the ATSAMD10 enabling easy integration of the device in a custom design.
- Onboard debugger with full source level debugging support in Atmel Studio
- Auto ID for board identification in Atmel Studio 6.2
- Access to all signals on target MCU
- One green status LED, one yellow user LED, one mechanical user push button and one touch button
- Virtual COM port (CDC)
- 8MHz external target clock
- USB powered
- Arduino shield compatible footprints
- Target SWD bus header footprint
