The IMC 1,5/ 2-ST-3,81 from Phoenix Contact is a 2 position pluggable PCB terminal block with 3.81mm pitch spacing. This terminal block is suitable for wire size ranging from 28AWG to 16AWG.
Green colour housing
Polyamide (PA) insulating material
1.5mm2 nominal cross section area
Rated voltage (III/2) is 160V and maximum load current is 8A
Rated surge voltage (II/2) is 2.5kV
Tin contact surface
M2 threaded screw
Insulating material group I
Connection in accordance with EN-VDE and CUL standard
