The VL6180XV0NR/1 is a Proximity and Ambient Light Sensing (ALS) Module based on FlightSense? technology. The module is designed for low power operation. Ranging and ALS measurements can be automatically performed at user defined intervals. Multiple threshold and interrupt schemes are supported to minimize host operations. Host control and result reading is performed using an I2C interface. Optional additional functions, such as measurement ready and threshold interrupts, are provided by two programmable GPIO pins.
- Three-in-one smart optical module - Proximity sensor, ambient light sensor, VCSEL light source
- Fast, accurate distance ranging
- Measures absolute range from 0 to above 10cm
- Independent of object reflectance
- Ambient light rejection
- Cross-talk compensation for cover glass
- Distance and signal level can be used by host system to implement gesture recognition
- High dynamic range ambient light sensor
- Accurate/sensitive in ultra-low light ambient light sensor
- Calibrated output value in lux, ambient light sensor
