RI-I16-114A-01 -

制造商：

TEXAS INSTRUMENTS TEXAS INSTRUMENTS

制造商产品编号：

RI-I16-114A-01

仓库库存编号：

2392502

技术数据表：

(EN)

The RI-I16-114A-01 Tag-it HF-I standard transponder inlay 24.2mm circular consist of 13.56MHz high frequency (HF) transponder. This product offer a user accessible memory of 256bits, organized in eight blocks, and an optimized command set available in five different antenna shapes, with frequency offset for integration into paper, PVC, or other substrates. The Tag-it HF-I standard transponder inlay is manufactured with patented laser tuning process to provide consistent read performance. Prior to delivery, the transponder undergo complete functional and parametric testing, in order to provide the high quality that customers have come to expect. The Tag-it HF-I standard transponder inlay is well suited for a variety of applications.

• ISO/IEC 15693-2, -3; ISO/IEC 18000-3 Compliant
• 256bit user memory in 8bit × 32bit blocks
• Application family identifier (AFI)
• Simultaneous identification of tags up to 50 tags per second (reader/antenna dependent)
• ASK/FSK transmission principle
